LED Edge-lit Module ( MOX268E)
360° LED neon flex which can be freely bent, a variety of accessories auxiliary modeling installation, showing different lighting effects, can be used in office places, art galleries, coffee shops and other places atmosphere auxiliary lighting lighting effects.
-The housing using ABS flame retardant engineering material, high flame retardant, high safely and reliability.
-Adopt high bright SMD 2835 LED, low light degradation, quick heat dissipation, high lighting efficiency
-Injection craft, aluminum PCB exposed with better heat dissipation
-Stable & reliable performance, long lifespan & good consistency
-CE & RoHS certificates, IP65 waterproof
Parametersnge
| ltems | parameters |
| Part NO. | MOX268E |
| LED | 2835 |
| Color | Pure white/Cold white |
| CCT(K) | 7000-8000/9000-12000 |
| Voltage ( V ) | 12 |
| Power ( W ) | 2.5 |
| Lumen Output( LM ) | 220 |
| Light efficiency (LM/W) | 88 |
| Optical lens( °) | 10X65 |
| Standard group no.（PCS） | 20 |
| Driving mode | Constant voltage |
| Weight(g/pcs) | 65 |
| Life time | 3years/25000H |
| Work environment（℃） | -25-+60 |
| Storage temperature（℃） | -25-+80 |
| IP Rank | IP65 |
Dimension
Light distribution
Connection
Application cases
